Specs for the 1/3 and others are below.

OIL FREE COMPRESSOR 1/3 HP VACUUM PUMP:

115V, 60HZ, 4.0A 3.5 cfm

FREE FLOW MAX: 3.0-4.4 CFM /

MAX PRESSURE: 40 PSI / 11 BAR

MAX VACUUM: 23-24" HG

THERMALLY INSULATED, INSUL CLASS B

WITH

 CAPACITOR:

10/15/20uf +/- 5/10% mk

450vac cl A 25/85/21

A15E10  50/60 hz



Hakko HK25LP Linear Air Pump

Hakko HK25LP Linear Air Pump
Matala introduces the new Hakko HK-25LP Linear air pump.

This new body style is made of high quality composite resin that is very suitable for outdoor use at an affordable price. The large air filter is mounted on the side of the pump for easy cleaning. All internal components are industrial grade quality and the pump comes with a 36 month warranty.

The Hakko Air Pump 25LP will deliver a maximum of 32 Liters Per Minute.

It is a small unit with a surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 5/8" O.D. 6 foot power cord supplied.





Item #

 Description



HK25LP Hakko HK25LP Linear Air Pump Locate a Dealer





Hakko HK40LP Linear Air Pump


Matala introduces the new Hakko HK-40LP Linear air pump.

This new body style is made of high quality composite resin that is very suitable for outdoor use at an affordable price. The large air filter is mounted on the side of the pump for easy cleaning. All internal components are industrial grade quality and the pump comes with a 36 month warranty.

The Hakko Air Pump 40LP will deliver a maximum of 70 Liters Per Minute.

It is a small unit with surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 5/8" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-40LP

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.13 (1.85psi)
Rated Performance lpm (cfm) 51
Power (W) 40
Noise Level (dB) 35
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.38
Closed Pressure / psi 5.5 204 x 174 x 215 mm •CUL
•CE
•JET



Weight (kg) 5.4 / 11.9





Hakko HK40L Linear Air Pump

Hakko HK40L Linear Air Pump
The Hakko HK-40L Linear air pump represents a top of the line Liner Air Compressor with 36 month warranty.

The Hakko Air Pump 40 will deliver a maximum of 70 Liters Per Minute.

This is a cast iron body style. It is a small unit with surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 5/8" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-40

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.13 (1.85psi)
Rated Performance lpm (cfm) 51
Power (W) 40
Noise Level (dB) 35
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.38
Closed Pressure / psi 5.5 204 x 174 x 215 mm •CUL
•CE
•JET



Weight (kg) 5.4 / 11.9




Item #

 Description



28018 Hakko HK40L Linear Air Pump Locate a Dealer





Hakko HK60L Linear Air Pump

Hakko HK60L Linear Air Pump
The Hakko HK-60L Linear air pump represents a top of the line Liner Air Compressor with 36 month warranty.

The Hakko Air Pump 60 will deliver a maximum of 82 Liters Per Minute.

This is a cast iron body style. It is a small unit with surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 5/8" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-60

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.15 (2.13psi)
Rated Performance lpm (cfm) 68
Power (W) 63
Noise Level (dB) 38
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.46
Closed Pressure / psi 6.7 204 x 174 x 215 mm •CUL
•CE
•JET

Weight (kg) 6.3 / 13.8




Item #

 Description



28022 Hakko HK60L Linear Air Pump Locate a Dealer





Hakko HK80L Linear Air Pump

Hakko HK80L Linear Air Pump
The Hakko HK-80L Linear air pump represents a top of the line Liner Air Compressor with 36 month warranty.

The Hakko Air Pump 80 will deliver a maximum of 100 liters per minute.

This is a cast iron body style. It is a small unit with surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 5/8" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-80

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.15 (2.13psi)
Rated Performance lpm (cfm) 86
Power (W) 85
Noise Level (dB) 38
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.54
Closed Pressure / psi 7.8 204 x 174 x 215 mm •CUL
•CE
•JET

Weight (kg) 6.3 / 13.8




Item #

 Description



28023 Hakko HK80L Linear Air Pump Locate a Dealer





Hakko HK100L Linear Air Pump

Hakko HK100L Linear Air Pump
The Hakko HK-100 Linear air pump represents a top of the line Liner Air Compressor with 36 month warranty.

The Hakko Air Pump 100 will deliver a maximum of 120 Liters Per Minute .

Hakko Air Pumps are sleek in design.

This is a cast iron body style. They are small units with a surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.
•High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Hakko air pumps utilize linear- motor theorem to reduce power consumption during full operation. Units are extremely quite utilizing spectrum analysis technology in order to decrease any mechanical noise.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.

Outlet fitting is 5/8" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-100

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.18 (2.56psi)
Rated Performance lpm (cfm) 105
Power (W) 116
Noise Level (dB) 40
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.45
Closed Pressure / psi 6.5 260 x 199 x 244 mm •CUL
•CE
•JET

Weight (kg) 8.9 / 19.6




Item #

 Description



28021 Hakko HK100L Linear Air Pump Locate a Dealer





Hakko HK120L Linear Air Pump

Hakko HK120L Linear Air Pump
The Hakko HK-120 Linear air pump represents a top of the line Liner Air Compressor with 36 month warranty.

The Hakko Air Pump 120 will deliver a maximum of 138 Liters Per Minute.

This is a cast iron body style. It is a small unit with surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.


Outlet fitting is 1" O.D. 6 foot power cord supplied.

No oil needed for lubrication making the Hakko easy to maintain.


Model / Item

HK-120

Application:

Features & Benefits:

Rated Voltage (V) AC 115 (AC 110/115/120 or
AC 220/230/240) •Aeration
•Liquid agitation
•Mamut pump for air lift
•Aerobic treatment
 •High Efficiency
•Simple Maintenance
•Completely Oil-Free
•Overload Protection
•Silent Operation
•Long Life Expectancy

Power Supply Frequency (Hz) 56 / 60
Normal Pressure Bar (psi) 0.20 (2.84psi)
Rated Performance lpm (cfm) 121
Power (W) 126
Noise Level (dB) 42
Maximum dimensions:

Certificate:

Closed Pressure / Bar 0.54
Closed Pressure / psi 7.8 260 x 199 x 244 mm •CUL
•CE
•JET

Weight (kg) 8.9 / 19.6




Item #

 Description



28020 Hakko HK120L Linear Air Pump Locate a Dealer





Hakko HK150L, HK200L, & HK250L Linear Air Pumps

Hakko HK150L, HK200L, & HK250L Linear Air Pumps
The Hakko 150L, 200L, and 250L are the latest air pumps in our line of Hakko Linear Air Pumps.

These high volume pumps are suitable for ponds or lakes larger than 12,000 gallons.
•Very rugged, reliable and weather resistant.
•Outlet fitting is 1" OD.
•Power cord is 80 inches long (6.5 ft).
•Cast Iron body style.
•3 year Limited Warranty.




HK 150L has a maximum air flow of 210 liters per minute. Max depth 13 ft deep.

HK 200L has a maximum air flow of 290 liters per minute. Max depth 12 ft deep.

HK 250L has a maximum air flow of 370 liters per minute. Max depth 13 ft deep.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.



Outlet fitting is 1" O.D. 6 foot power cord supplied.

Pump Curve

Pump CurvePump CUrvePlease call for more details.


  PDF File for Hakko HK150L, HK200L, & HK250L Linear Air Pumps




Hakko HK25L Vacuum Air Pump

Hakko HK25L Vacuum Air Pump
The Hakko HK-25L is a vacuum style air pump suitable for industrial use such as medical or technical industries and represents a top of the line vacuum air compressor with 36 month warranty.

The Hakko Air Pump 25 will deliver a maximum of 32 Liters Per Minute.

This is a cast iron body style. It is a small unit with a surprisingly high output. The Hakko air pumps are built to last with a very durable body and mechanics meaning years and years of everlasting quality airflow.

Very low noise 32/38 dB at 1 meter, low power consumption, Silent operation, Completely oil free, Overload protection with Auto off/on switch for overheat situations. Low power consumption. UL and CE listed for outdoor use.
